快速入门(NFC_RFID_Dynamic_Tags_-_Quick_Start_Guide_X-NUCLEO-NFC01A1).pdf
Quick Start Guide
Dynamic NFC tag expansion board based on M24SR
for STM32 NUCLEO
(X-NUCLEO-NFC01A1)
Version 1.1 (May 19, 2015)
Overview 2
1
2
3
4
Introduction to the STM32 Open Development Environment
STM32 Nucleo Dynamic NFC tag expansion board
• Hardware overview
• Software overview
Documents & Related Resources
Setup & Demo Examples
Overview 3
1
2
3
4
Introduction to the STM32 Open Development Environment
STM32 Nucleo Dynamic NFC tag expansion board
• Hardware overview
• Software overview
Documents & Related Resources
Setup & Demo Examples
STM32 Open Development Environment
Lowering the Barriers for “Developers”
4
Easy access to technology
Device
Prototype
Form factor
Device
Final
Device
Idea
Application
SW Development
Field
Testing
Commercial
SW
Market
Fast, flexible, affordable and based on commercial components
Scalable SW for faster time to Market
STM32 Open Development Environment
5
The STM32 Open Development Environment consists of a set
of modular developer boards and a SW environment
designed around the STM32 microcontroller family
STM32 Nucleo
STM32Cube
development boards
development software
STM32 Nucleo
STM32Cube
expansion boards
expansion software
Compatibility with multiple Development Environments
STM32 Open Development Environment
Building block approach
6
The building blocks
Your need
Our answer
Accelerometer, gyroscope
Inertial modules, magnetometer
Pressure, temperature, humidity, UV
Proximity, microphone
Sense
COLLECT
Bluetooth LE, Sub-GHz radio
NFC, Wi-Fi, GNSS
Connect
TRANSMIT
Audio amplifier
Touch controller
Operation Amplifier
Translate
ACCESS
Stepper motor driver
DC & BLDC motor driver
Move / Actuate
CREATE
Energy management & battery
Power
POWER
General purpose microcontrollers
Secure microcontrollers
Process
PROCESS
www.st.com/stm32ode
Software
STM32 Nucleo Development Board
7
• Based on ST’s 32-bit ARM Cortex-M
based STM32 microprocessors
• A Boards with 1 MCU and hardware to
program/debug
• Two connectors to connect to
companion chips boards
• For all STM32 families
Flexible board power supply
through USB or external source
Integrated Debugging and
programming probe
Arduino UNO extension
connectors easy access to add-
ons (*)
STM32 Microcontroller
Morpho extension headers:
Direct access to all STM32 I/Os
complete product range
from ultra-low power to high-performance
(*) thanks to the electrical compatibility it can be used as a shield for Arduino UNO R3 or similar
Overview 8
1
2
3
4
Introduction to the STM32 Open Development Environment
STM32 Nucleo Dynamic NFC tag expansion board
• Hardware overview
• Software overview
Documents & Related Resources
Setup & Demo Examples
