Ordering number : CNA1482A LV8731V Bi-CMOS PWM Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to "standard application", intended for the use as general electronics equipment (home appliances, AV equipment, communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee thereof. If you should intend to use our products for applications outside the standard applications of our customer who is considering such use and/or outside the scope of our intended standard applications, please consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our customer shall be solely responsible for the use. Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate the performance, characteristics, and functions of the described products in the independent state, and are not guarantees of the performance, characteristics, and functions of the described products as mounted in the customer's products or equipment. To verify symptoms and states that cannot be evaluated in an independent the customer should always evaluate and test devices mounted in the customer's products or device, equipment. 北京时代超群电器科技有限公司电话：010-87197282 62310 No.A1482-1/25

LV8731V k k k k 北京时代超群电器科技有限公司电话：010-87197280

LV8731V k k k k k TOP VIEW 15.0 44 1 0.65 (0.68) 0.22 SIDE VIEW SIDE VIEW BOTTOM VIEW 23 22 0.2 (4.7) SANYO : SSOP44K(275mil) 北京时代超群电器科技有限公司电话：010-87197280

LV8731V 北京时代超群电器科技有限公司电话：010-87197280

LV8731V LV8731V Top view VG VM CP2 CP1 VREG5 ATT2 ATT1 EMO CEM 1 2 3 4 5 6 7 8 9 EMM 10 CHOP 11 MONI 12 RST/BLK 13 STEP/DC22 14 FR/DC21 15 MD2/DC12 16 MD1/DC11 17 DM 18 OE 19 ST 20 VREF 21 GND 22 44 OUT1A 43 OUT1A 42 PGND 41 NC 40 NC 39 VM1 38 VM1 37 RF1 36 RF1 35 OUT1B 34 OUT1B 33 OUT2A 32 OUT2A 31 RF2 30 RF2 29 VM2 28 VM2 27 NC 26 NC 25 PGND 24 OUT2B 23 OUT2B 北京时代超群电器科技有限公司电话：010-87197280

LV8731V 北京时代超群电器科技有限公司电话：010-87197280

LV8731V VREG5 GND VREG5 GND 10k 100k 20k 10k 80k 38 39 28 29 43 32 44 33 34 23 35 24 10k 25 42 36 37 30 31 500 500 GND 北京时代超群电器科技有限公司电话：010-87197280

LV8731V VREG5 4 2 3 1 100 GND VREG5 GND VM 500 GND VREG5 GND 2k 78k 26k 北京时代超群电器科技有限公司电话：010-87197280
